MDM-9PSB-A174
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | Tariff No | 85369010 |
Electrical
| Current Rating (Max) | 3A | ||
Mechanical
| Depth | 10.57mm | Pitch | 0.05in |
| Width | 7.82mm | Length | 19.94mm |
| Weight | 0 | Packaging | Bulk |
| Termination | Solder Pot | Weight (g): | 0.99001 |
| Contact Size | 24 | Contact Type | Signal |
| Mounting Type | Panel Mount | Connector Type | Plug, Male Pins |
| Contact Finish | Gold | Flange Feature | Housing/Shell (Unthreaded) |
| Number of Rows | 2 | Connector Style | D-Type, Micro-D |
| Contact Material | Copper Alloy | Housing Material | Liquid Crystal Polymer (LCP) |
| Size / Dimension | 19.94 x 7.82 x 10.57mm | Number of Contacts | 9 |
| Contact Termination | :Solder | Number of Positions | 9 |
| Shell Material, Finish | Aluminum, Nickel Plated, Electroless | 1st Connector Mounting Type | :Cable |
| Shell Size, Connector Layout | 0.050 Pitch x 0.043 Row to Row | ||
Product Info
| Type | Micro D-Subminiature | Gender | PIN |
| Series | MDM | Features | Shielded |
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
Documents & Media
Sourcing & traceability
- Datasheet
- Microminiature Connectors Catalog
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
