100R07X105KV4T
| Category |
对参数有疑问？问 AI 助手
Business
| Product | General Type MLCCs | Other Names | 709-1222-2 |
| Standard Package | 10,000 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| Tariff No | 85322400 | Rad Hardened | No |
Electrical
| Voltage | 10VDC | Tolerance | ±10% |
| Capacitance | 1.0µF | Range deg/s | :JOHANSON - TANCERAM Series |
| Voltage Rating | 10V | Capacitance - Input | :0402 [1005 Metric] |
| Capacitance @ Vr, F | :X5R | Dissipation Factor (DF) | 10 |
Mechanical
| Depth | 0.51 mm | Width | 0.51 mm |
| Height | 0.64 mm | Weight | 0.000002 |
| Diameter | Not Required mm | Packaging | Tape & Reel (TR) |
| Construction | SMT Chip | Mounting Type | Surface Mount, MLCC |
| Mounting Style | Surface Mount | Number of Pins | :2 |
| Package / Case | 0402 (1005 Metric) | Material Finish | :MSL 1 - Unlimited |
| Thickness (Max) | 0.025" (0.64mm) | Length - Overall | 1.02 mm |
| Size / Dimension | 0.040" L x 0.020" W (1.02mm x 0.51mm) | Termination Style | SMD/SMT |
| Mounting Hole Diameter | 1005 | Wire Gauge or Range - AWG | Not Required |
Product Info
| Type | Tanceram High Capacitor | Series | R07 |
| Applications | SMPS Filtering | Failure Rate | Not Required |
Environmental
| Operating Temperature | -55°C ~ 85°C | Temperature Coefficient | X5R |
Documents & Media
PDF Document
.JPG&w=3840&q=75)
Sourcing & traceability
- Datasheet
- JDI_Full-Catalog_2012-01.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
