500R15N220JV4T
| Category |
对参数有疑问？问 AI 助手
Business
| Product | General Type MLCCs | Other Names | 709-1172-2 |
| Standard Package | 4,000 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Rad Hardened | No |
Electrical
| Voltage | 50VDC | Tolerance | ±5% |
| Capacitance | 22pF | Voltage Rating | 50V |
Mechanical
| Depth | 1.27 mm | Width | 1.27 mm |
| Height | 1.27 mm | Diameter | Not Required mm |
| Packaging | Tape & Reel (TR) | Construction | SMT Chip |
| Mounting Type | Surface Mount, MLCC | Mounting Style | Surface Mount |
| Package / Case | 0805 (2012 Metric) | Thickness (Max) | 0.050" (1.27mm) |
| Length - Overall | 2.03 mm | Size / Dimension | 0.080" L x 0.050" W (2.03mm x 1.27mm) |
| Termination Style | SMD/SMT | Mounting Hole Diameter | 2012 |
| Wire Gauge or Range - AWG | Not Required | ||
Product Info
| Type | Surface Mount MLCC | Series | R15 |
| Applications | General Purpose | Failure Rate | Not Required |
Environmental
| Operating Temperature | -55°C ~ 125°C | Temperature Coefficient | C0G, NP0 |
Documents & Media
PDF Document
PDF Document
Similar Parts
Sourcing & traceability
- Datasheet
- MLCC SMD 10-200VDC
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
