04R-JWPF-VSLE-S
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1,000 | ||
Compliance
| RoHS | Compliant | ||
Electrical
| Voltage Rating | 100 V ac/dc | Current Rating (Max) | 3A |
| Connector - Voltage Input | Crimp | ||
Mechanical
| Color | Natural | Depth | 16.5mm |
| Pitch | 0.079" (2.00mm) | Width | 5.5mm |
| Length | 10.7mm | Packaging | Bulk |
| Orientation | 直 | Weight (g): | 7.95 |
| Contact Form | Female Socket | Contact Type | Female Socket |
| Mounting Type | Free Hanging (In-Line) | Connector Type | Receptacle |
| Fastening Type | Latch Lock | Number of Rows | 1 |
| Package / Case | 40X29X23CM | Housing Material | PBT |
| Number of Contacts | 4 | Contact Termination | Crimp |
| Number of Positions | 4 | ||
Product Info
| Name | 塑壳 | Note | Contacts Not Provided |
| Unit | PCS | Gender | Female |
| Series | JWPF | Features | JIS C 0920 Grade Level 7 |
| Quantity | 10000.0 | Main Purpose | JIS C 0920 Grade Level 7 |
| Output Configuration | Free Hanging (In-Line) | Manufacturing Country | 马来西亚 |
| Equipment Part Numbers | cJWPF-WW.pdf | Minimum Order Quantity | 1 |
| For Use With/Related Products | JWPF 系列插座连接器 | ||
Environmental
| Operating Temperature | +85°C | ||
