B10B-PH-K-S
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 455-1271 | Standard Package | 500 |
Compliance
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Voltage - Test | 800 | Voltage Rating | 100 |
| Number of Poles | 10 | Contact Resistance | 20 mohm |
| Current Rating (Max) | 2 A | Insulation Resistance | 1000 MOhm |
| Voltage - Supply (Min) | 100VDC/100VAC | ||
Mechanical
| Color | Natural | Depth | 4.5 mm |
| Pitch | 0.079" (2.00mm) | Height | 6 mm |
| Packaging | Bulk | Body Color | 21.9 |
| Termination | Press-Fit | Contact Form | Male Pin |
| Contact Type | Male Pin | Housing Color | White |
| Mounting Type | Through Hole | Connector Type | Header, Shrouded |
| Contact Finish | Tin-Lead | Mounting Style | Through Hole |
| Number of Rows | 1 | Contact Material | Brass |
| Housing Material | Polyamide 66 | Length - Overall | 21.9 mm |
| Number of Contacts | 1 | Number of Positions | 10 |
| 1st Connector Gender | Male | Number of Positions/Bay/Row | All |
Product Info
| Type | Shrouded Header | Gender | HDR |
| Series | PH | Amplifier Type | 18 |
| Connection Method | Wire-Board | Output Configuration | Through Hole |
| Number of Positions Loaded | All | ||
Environmental
| Operating Temperature | -25C to 85C | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- PH Series (Crimp Style)
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
