Business
| Other Names | 455-1235 | Standard Package | 2,000 |
Compliance
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Voltage - Test | 500 | Voltage Rating | 50 |
| Number of Poles | 3 | Contact Resistance | 20 mOhm |
| Current Rating (Max) | 1 A | Insulation Resistance | 500 MOhm |
Mechanical
| Color | Natural | Pitch | 0.059" (1.50mm) |
| Packaging | Bulk | Body Color | 6 |
| Termination | Press-Fit | Contact Type | Male Pin |
| Mounting Type | Through Hole | Connector Type | Header, Shrouded |
| Contact Finish | Tin-Lead | Number of Rows | 1 |
| Contact Material | Tin-plated phosphor bronze | Housing Material | Polyamide (PA/Nylon) |
| Number of Positions | 3 | 1st Connector Gender | Male |
Product Info
| Series | ZH | Amplifier Type | 3 |
| Connection Method | Wire-Board | Number of Positions Loaded | All |
Environmental
| Operating Temperature | -25...+85 °C | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- ZH Connector
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
