Business
| Standard Package | 1,000 | ||
Compliance
| RoHS | Compliant | ||
Electrical
| Current Rating (Max) | 3 A | Voltage - Supply (Min) | 250VDC/250VAC |
Mechanical
| Color | Natural | Depth | 7.1mm |
| Pitch | 0.098" (2.50mm) | Width | 3.8mm |
| Height | 3.8 mm | Length | 17mm |
| Packaging | Bulk | Orientation | 直 |
| Contact Type | Female Socket | Housing Color | White |
| Mounting Type | Free Hanging (In-Line) | Connector Type | Receptacle |
| Number of Rows | 1 | Housing Material | Nylon |
| Length - Overall | 17 mm | Number of Contacts | 6 |
| Contact Termination | Crimp | Number of Positions | 6 |
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Series | EH | For Use With/Related Products | Disconnectable Crimp Connector |
Environmental
| Operating Temperature | -25C to 85C | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- EH Connector (RoHS)
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
