S7B-PH-K-S(LF)(SN)
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 500 | ||
Compliance
| RoHS | Compliant | ||
Electrical
| Voltage Rating | 100 V ac/dc | Current Rating (Max) | 2A |
Mechanical
| Color | Natural | Pitch | 0.079" (2.00mm) |
| Packaging | Bulk | Orientation | 直角 |
| Termination | Press-Fit | Contact Form | Male Pin |
| Contact Type | Male Pin | Mounting Type | Through Hole, Right Angle |
| Connector Type | Header, Shrouded | Contact Finish | Tin |
| Number of Rows | 1 | Contact Material | Brass |
| Termination Rows | 焊接 | Number of Contacts | 7 |
| Number of Positions | 7 | Number of Positions/Bay/Row | All |
Product Info
| Type | Shrouded Header | Series | PH |
| Coverage | 覆盖 | Base Product Number | S7B |
| Output Configuration | Through Hole, Right Angle | Number of Positions Loaded | All |
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- PH Series
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
