Business
| Standard Package | 1,000 | ||
Compliance
| RoHS | Compliant | Material Flammability Rating | UL 94 V-0 |
Electrical
| Voltage - Test | 1000 | Voltage Rating | 250 |
| Number of Poles | 10 | Contact Resistance | 10 mOhm |
| Current Rating (Max) | 3 A | Insulation Resistance | 1000 MOhm |
| Voltage - Supply (Min) | 250VDC/250VAC | ||
Mechanical
| Color | Natural | Depth | 7.75mm |
| Pitch | 0.098" (2.50mm) | Width | 5.7mm |
| Height | 5.7 mm | Length | 27.3mm |
| Packaging | Bulk | Body Color | 27.3 |
| Wire Gauge | 22-30 AWG | Orientation | 直 |
| Contact Type | Female Socket | Housing Color | White |
| Mounting Type | Free Hanging (In-Line) | Connector Type | Receptacle |
| Number of Rows | 1 | Contact Material | Tin-plated phosphor bronze |
| Housing Material | Nylon | Length - Overall | 27.3 mm |
| Number of Contacts | 10 | Contact Termination | Crimp |
| Number of Positions | 10 | ||
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | Male | Series | XH |
| Amplifier Type | 22.5 | Connection Method | Wire-Board |
| For Use With/Related Products | Removable crimp connector | ||
Environmental
| Operating Temperature | -25C to 85C | ||
Documents & Media
PDF Document
(SN).JPG&w=3840&q=75)
(SN).jpg&w=3840&q=75)
(SN).JPG&w=3840&q=75)
Sourcing & traceability
- Datasheet
- XH Connector
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
