KB2685EW
| Manufacturer | |
| Description | LED Displays & Accessories RED DIFFUSED LIGHT BAR LED LIGHT BAR 8.89X19.05MM RED LED Bars and Arrays RED DIFFUSED LIGHT BAR 8.89X19.05MMREDLIGHTBAR,DP,TUBE Displays Light Bar Size: 8.89X19.05mm Color: Red Lens Color: White Diffused Luminous Intensity (Typ.) : 25 mcd @20mA |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Led Light Bar | Lead Time | 56 Days |
| Other Names | 754-1188-5 | Subcategory | LED Light Bars, Arrays and Bar Graphs |
| Product Category | LED Displays & Accessories | Standard Package | 25 |
| Factory Pack Quantity | 25 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Current | 30mA | Wavelength | 625 nm |
| Luminous Flux | 25 mcd @20mA | Viewing Angle | N/A |
| Voltage Rating | 2V | Voltage - Supply | 2 V |
| Wavelength - Peak | 625nm | LED Forward Current | 30mA |
| Millicandela Rating | 40mcd | Wavelength - Dominant | 625nm |
| Power - Average Forward | 75 mW | Current - Average Rectified (Io) | 30 mA |
Mechanical
| Size | 8.89X19.05mm | Color | Red (x 8) |
| Material | GaAsP/GaP | Packaging | Tube |
| Common Pin | 16 | Lens Color | White |
| Mounting Type | Through Hole | Mounting Style | Thru-Hole |
| Lens Style/Size | Rectangle, 19.05mm x 8.89mm | Illumination Color | Red |
Product Info
| Type | Displays | Lens Type | Diffused, White |
| Card Standard | Light Bar | Configuration | Bar - Single, DIP |
| Character Size | 8.89 mm x 19.05 mm | Industry Aliases | KB-2685EW |
| Number of Segments | 4 | ||
Environmental
| Operating Temperature | + 85 C | Luminous Flux @ Current/Temperature | 25 mcd |
