Business
| Product | Common Mode Filters | Lead Time | 84 Days |
| Other Names | 240-2463-1 | Subcategory | Common Mode Chokes |
| Product Category | EMI Filter Beads, Chips & Arrays | Standard Package | 375 |
| Factory Pack Quantity | 375 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Current | 20A | Impedance | 170 Ohm |
| Filter Type | Power Line | Test Frequency | 100 MHz |
| DC Resistance (DCR) | 1 mOhm Max | Current Rating (Max) | 20 A |
| Resistance - Initial (Ri) (Min) | 1 mOhms | ||
Mechanical
| Weight | 0.123680 oz | Packaging | Tape and Reel |
| Height (Max) | 0.413" (10.49mm) | Mounting Type | Surface Mount |
| Package / Case | Vertical, 4 Flat Lead | Size / Dimension | 0.435" L x 0.335" W (11.05mm x 8.51mm) |
| Termination Style | SMD/SMT | ||
Product Info
| Number of Lines | 2 | ||
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- CM3440Z171R-10-A-2.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
