Electrical
| Voltage Rating | 500 V | Conductor Strand | Stranded |
| Current Rating (Max) | 12 A | 2nd Harmonic, Typ (dBc) | H05RR-F |
| DC Resistance (DCR) (Max) | 26 Ω/km | ||
Mechanical
| Length | 100m | Cable Type | Multicore |
| Wire Gauge | 18 AWG | Shield Type | 无屏蔽 |
| Cable Length | 100m | Conductor Type | 股绞电线 |
| Insulation Color | 黑色 | Cable Termination | 否 |
| Pitch - Connector | 24 x 0.2 mm | Color - Connectors | Black |
| Conductor Material | Copper | Cross Section Shape | 0.75 mm |
| Insulation Material | Rubber | Number of Positions | 4 |
| Jacket (Insulation) Material | Rubber | Diameter - Inside, Non-Expanded | 0.2 mm |
Product Info
| Type | 318TRS | Number of Cores | 4 |
Environmental
| Operating Temperature | +60°C | ||
