LTV-815

Manufacturer	Lite-On Technology Corporation
Description	Optocoupler DC-IN 1-CH Darlington DC-OUT 4-Pin PDIP Transistor Output Optocouplers Optocoupler Phototrans OPTOCOUPLER DARL 5KVRMS 4DIP Optocoupler Darlington Output, 35V, DIP4 OPTOCOUPLER >600% DARLINGTON DI
Category	OptoelectronicsDiscrete LED IndicationOptocouplers

对参数有疑问？问 AI 助手

Business

Product Category	Transistor Output Optocouplers	Standard Package	Rail / Tube
Factory Pack Quantity	100	Standard Package Name	PDIP

Output	Photodarlington	Channels	1
Fall Time	250000 ns	Input Type	DC
Output Type	DC	Power - Max	200 mW
Power - Rated	0.2 W	Fall Time (Typ)	0.053 ms
Rise Time (Typ)	300 us	Voltage - Supply	35 V
Number of Channels	1	Number of Elements	1
LED Forward Current	50 mA	LED Forward Voltage	1.2 V
Voltage - Breakdown	6 V	Voltage - Isolation	5000 Vrms
Vce Saturation (Max)	1V	Voltage - Input (Min)	35 V
Power - Average Forward	200 mW	Power Dissipation (Max)	200 mW
Vce(on) (Max) @ Vge, Ic	35 V	Voltage Regulation - Load	6 V
Current - Input Bias (Max)	50 mA	Current - Output / Channel	80mA
Current Transfer Ratio (Max)	7500 %	Current Transfer Ratio (Min)	7500 %
Current - Collector (Ic) (Max)	80 mA	Current - DC Forward (If) (Max)	50 mA
Current - Collector Cutoff (Max)	0.08 A	Voltage - Reverse Standoff (Typ)	6 V
Max Propagation Delay @ V, Max CL	250 us	Voltage - Forward (Vf) (Max) @ If	1.4 V
Voltage - Gate Trigger (Vgt) (Max)	6 V	Current - Average Rectified (Io) (per Diode)	50mA

Manufacturer

Lite-On

Configuration

1 Channel

Operating Temperature

-30 to 100 °C
