0313030.HXP
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 1 | Product | Specialty Fuses |
| Unit Pack | 0 | Product Category | Fuses |
| Standard Package | 100 | Factory Pack Quantity | 100 |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85361010 | Approval Agency | UL |
Electrical
| Indicator | Without Indicator | Resistance | 0.0012 Ohms |
| Melting I2t | 26900 | Response Time | Slow |
| Voltage Rating | 32 V | Interrupt Output | 300 Amps |
| DC Cold Resistance | 0.0012 Ohm | Voltage - Rated AC | :32V |
| DC Resistance (DCR) | 0.0012Ohms | Current Rating (Max) | 30 A |
| Fuse Characteristics | time-lag | Voltage - Input (Min) | 32 |
| Blowout Characteristic | :Slow Blow | Voltage - Supply (Min) | 300A |
Mechanical
| Size | 3AG | Weight | 0.002 |
| Diameter | 6.35 mm | Packaging | Bulk |
| Termination | Cartridge | Body Material | Glass |
| Mounting Type | Holder | Mounting Style | Holder |
| Package / Case | 31.75 mm | Material - Body | Glass |
| Length - Overall | 31.75 | Material - Blade | Glass |
| Package Quantity | 100 | Primary Material | Cylinder |
| Size / Dimension | 31.75 mm L x 6.35 mm D | Termination Style | Clip |
| Number of Contacts | 2 | Supplier Device Package | Cartridge Fuses |
Product Info
| Spg | 100 | Type | Axial Lead and Cartridge Fuse |
| Class | Supplemental | Energy | 26900A2s |
| Series | 313 | Fuse Size | 3AG (6.3 mm x 32 mm) |
| Fuse Type | Time Delay / Slow Blow | Manufacturer | 313PSeries |
| Product Type | Glass Fuse | Number of Units | 1 |
Environmental
| Must Operate | Slow Blow | Operating Temperature | - 55 C to + 125 C |
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 313P_315P.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
