0451.630MRL
| Manufacturer | |
| Description | Fuses 125V.63A Fuse Chip Very Fast Acting 0.63A 125V SMD Solder Pad 2410 Ceramic T/R FUSE .630A 125V FAST NANO2 SMD Littelfuse 0.630A FF, 125V Surface Mount Fuses 125V.63A FUSE, QUICK BLOW, SMD, 630MA FuseSMD125VFFNANO2Au0.630A Fuse: fuse; ultra rapid; ceramic; 630mA; 125VAC; 125VDC; SMD
sale Littelfuse 630mA 不可复位表面固定熔断器, FF熔断速度, 125 V 630mA 125V fast SMD NANO |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Surface Mount Fuses | Other Names | F2575CT |
| Product Category | Fuses | Standard Package | 1,000 |
| Factory Pack Quantity | 1000 | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85361010 |
| Approval Agency | CSA, UL | ||
Electrical
| Resistance | 0.305 Ohms | Melting I2t | 0.143 |
| Response Time | Fast | Voltage Rating | 125 V |
| Frequency - Max | FF | Interrupt Output | 50 Amps at 125 VoltsAC/DC |
| DC Cold Resistance | 0.305 Ohm | Current Rating (Max) | 630 mA |
| Fuse Characteristics | ultra rapid | Voltage - Input (Min) | 125 |
| Blowout Characteristic | :Very Fast Acting | Voltage - Supply (Min) | 50A |
Mechanical
| Depth | :2.69mm | Width | 2.69 mm |
| Height | 2.69mm | Length | 6.10mm |
| Weight | 0.001 | Packaging | Reel |
| Body Material | Ceramic | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 2.69 mm |
| Material Finish | :MSL 1 - Unlimited | Length - Overall | 6.1 |
| Material - Blade | Ceramic | Package Quantity | 1000 |
| Size / Dimension | 6.1 mm L x 2.69 mm W | Termination Style | SMD/SMT |
| Number of Contacts | 2 | Contact Material - Plating | silver plated |
| Material - Housing & Prism | :Ceramic | ||
Product Info
| Spg | 1000 | Type | Nano Surface Mount Very Fast Acting Fuse |
| Series | 451 | Fuse Size | NANO |
| Fuse Type | Fast Blow | Product Type | Surface Mount Fuse |
| Number of Units | 5 | ||
Environmental
| Temperature | 260°C / 10 s | Must Operate | Very Fast |
| Operating Temperature | - 55 C to + 125 C | ||
