Business
| MOQ | 5000 | Unit Pack | 5000 |
| Other Names | SMAJ58ALFTR | Product Category | TVS Diodes - Transient Voltage Suppressors |
| Standard Package | 5,000 | Factory Pack Quantity | 5000 |
Compliance
| RoHS | Lead free by exemption / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85411000 | Automotive | NO |
| Rad Hardened | No | Leadfree Defin | RoHS-conform |
Electrical
| Channels | 1 Channel | Tolerance | 5% |
| TVS Polarity | :Unidirectional | Power - Rated | 400W |
| Current - Surge | 4.3 A | Voltage - Supply | 58V |
| Current - Leakage | 0.001 uA | Number of Elements | 1 |
| Power - Peak Pulse | 400W | Voltage - Clamping | 96.6V |
| Current - Trip (It) | 1 mA | Diode Configuration | :DO-214AC |
| Voltage - Breakdown | 68V | Contact Voltage (Max) | 58V |
| Power Line Protection | No | Voltage - Supply (Min) | 58 V |
| Power Dissipation (Max) | 0.4kW | Unidirectional Channels | 1 |
| Current - Peak Pulse (8/20us) | 4.3 A | Current - Peak Pulse (10/1000us) | 4.3A |
| Voltage - Reverse Standoff (Typ) | 58 V | ||
Mechanical
| Weight | 0.002 | Packaging | Tape & Reel (TR) |
| Mounting Type | Surface Mount | Number of Pins | :2 |
| Package / Case | SMA | Package Cooled | DO-214AC |
| Material Finish | :MSL 1 - Unlimited | Package Quantity | 5000 |
| Size / Dimension | 2.79 mm W x 4.5 mm L x 2.29 mm H | Termination Style | SMD/SMT |
| Number of Positions | 2 | Supplier Device Package | SMA |
Product Info
| Spg | 5000 | Type | Zener |
| Series | SMAJ | DELETED | Compliant |
| Polarity | Unidirectional | Matchcode | SMAJ58A |
| Structure | unidirectional | Diode Type | transil |
| Applications | Telecom | Number of Units | 1 |
| Standard Leadtime | 12 weeks | Application Specifics | UNIDIRECTI |
Environmental
| Operating Temperature | -55°C ~ 150°C | ||
Documents & Media
PDF Document
Similar Parts
Sourcing & traceability
- Datasheet
- Littelfuse_TVS-Diode_SMAJ.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
