PM-15-5
| Manufacturer | |
| Description | Linear and Switching Power Supplies 15W 5V 3A AC/DC Power Supply Single-OUT 5V 3A 15W 4-Pin PSU, ENCAPSULATED, 15W, 5V Pwr sup.unit: pulse; 15W; 5VDC; 3A; 85÷264VAC; 120÷370VDC; 140g Switching power supply 15 W 1 output, PM-15-5, Mean Well |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Switching Supplies | Product Category | Linear and Switching Power Supplies |
| Factory Pack Quantity | 120 | ||
Compliance
| RoHS | RoHS Compliant | Tariff No | 85044030 |
| Protection | overload, voltage growth | Approval Agency | :EN 60601, IEC 60601, UL 60601 |
Electrical
| Frequency | :440Hz | Efficiency | :76% |
| Output Type | :Fixed | Power - Max | :15W |
| Output Power | 15 W | Power - Rated | :15W |
| Voltage Rating | 85 VAC to 264 VAC, 120 VDC to 370 VDC | Current - Surge | :50A |
| Frequency - Max | :440Hz | Frequency - Min | :47Hz |
| Line Regulation | :1.0% | Load Regulation | :1.0% |
| Current - Output | :3A | Voltage - Supply | :264V |
| Number of Outputs | 1 | Power Supply Type | :Switch Mode |
| Output Ripple Voltage | :80mV | Voltage - Input (Min) | 5 VDC |
| DC Voltage - Input (Max) | :370VDC | Current - Output / Channel | 3 A |
Mechanical
| Depth | :22.7mm | Width | 53 mm |
| Height | 22.7 mm | Length | 75 mm |
| Weight | 0.15 | Size - Body | 75 x 53 x 22.7mm |
| Mounting Type | :PCB | Mounting Style | Chassis |
| Size / Dimension | 75 mm L x 53 mm W | ||
Product Info
| Features | rated parameters obtained at full load | Application | Medical |
| Applications | :Medical | Electrical Life | THT |
| Number of Units | 1 | ||
Environmental
| Operating Temperature | :70°C | Storage/Refrigeration Temperature | :85°C |
