0279-0-15-01-47-27-10-0
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Receptacles | Lead Time | 20 Days |
| Subcategory | Connector Contact | Product Category | Circuit Board Hardware - PCB |
| Standard Package | 500 | Factory Pack Quantity | 500 |
Compliance
| RoHS | No | EU RoHS | Not Compliant |
Electrical
| Contact Resistance | 10 | Current Rating (Max) | 4.5 A |
Mechanical
| Depth | 1.98 | Height | 1.98 |
| Length | 0.2 in | Plating | Tin / Lead over Nickel |
| Material | Brass | Packaging | Bulk |
| Tail Type | No Tail | Shield Type | No |
| Termination | Press Fit | Contact Size | 47 |
| Socket Depth | 0.165" (4.19mm) | Mounting Type | Through Hole |
| Connector Type | Connector Socket | Contact Finish | Gold Over Nickel |
| Flange Diameter | 0.078" (1.98mm) | Contact Material | Beryllium Copper Alloy |
| Length - Overall | 0.2 in | Diameter - Inside | 0.057 in |
| Pin Hole Diameter | 0.051" (1.30mm) | Diameter - Outside | 0.078 in |
| Accepts Pin Diameter | 0.025" ~ 0.037" (0.64mm ~ 0.94mm) | Mounting Hole Diameter | 0.062 in |
| Contact Finish Thickness | 30µin (0.76µm) | ||
Product Info
| Type | Pins | Gender | SKT |
| For Use With/Related Products | 0279-0-15-15-47-27-10-00279-0-15-80-47-27-10-0 | ||
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
Documents & Media
Sourcing & traceability
- Datasheet
- 0279-0-15-01-47-27-10-0
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
