0317-0-15-15-34-27-10-0
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Socket Pins | Product Category | IC & Component Sockets |
| Standard Package | 500 | Factory Pack Quantity | 500 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Contact Resistance | 10 | Current Rating (Max) | 8 |
Mechanical
| Depth | 3.05 | Packaging | Bulk |
| Tail Type | No Tail | Termination | Solder |
| Contact Size | 34 | Contact Type | Signal |
| Socket Depth | 0.220" (5.59mm) | Mounting Type | Straight |
| Connector Type | Connector Headers and PCB Recepta... | Contact Finish | Gold Over Nickel |
| Flange Diameter | 0.120" (3.05mm) | Contact Material | Beryllium Copper Alloy |
| Length - Overall | 0.253" (6.43mm) | Pin Hole Diameter | 0.064" (1.63mm) |
| Accepts Pin Diameter | 0.032" ~ 0.046" (0.81mm ~ 1.17mm) | Mounting Hole Diameter | 0.091" (2.31mm) |
| Contact Finish Thickness | 30µin (0.76µm) | ||
Product Info
| Gender | SKT | ||
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- 183-259709.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
