0405-0-15-15-34-27-04-0
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Receptacles | Lead Time | 20 Days |
| Subcategory | Connector Contact | Product Category | Circuit Board Hardware - PCB |
| Standard Package | 500 | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85369010 | ||
Electrical
| Contact Resistance | 10 | Current Rating (Max) | 8 |
Mechanical
| Depth | 2.29 | Length | 0.375 in |
| Weight | 0.002 | Plating | Gold over Nickel |
| Material | Brass | Packaging | Bulk |
| Tail Type | Standard Tail | Termination | Press Fit |
| Contact Size | 34 | Contact Type | Signal |
| Socket Depth | 0.220" (5.59mm) | Mounting Type | Straight |
| Tail Diameter | 0.030" (0.76mm) | Connector Type | Connector Headers and PCB Recepta... |
| Contact Finish | Gold Over Nickel | Flange Diameter | 0.090" (2.29mm) |
| Contact Material | Beryllium Copper Alloy | Length - Overall | 0.375 in |
| Diameter - Inside | 0.03 in | Pin Hole Diameter | 0.064" (1.63mm) |
| Diameter - Outside | 0.09 in | Number of Contacts | :1 |
| Contact Termination | :Press Fit Vertical | Accepts Pin Diameter | 0.032" ~ 0.046" (0.81mm ~ 1.17mm) |
| Mounting Hole Diameter | 0.084 in | Contact Finish Thickness | 30µin (0.76µm) |
| 1st Connector Mounting Type | :PCB | ||
Product Info
| Type | Pins | Gender | SKT |
| Series | :0405 | For Use With/Related Products | 0405-0-15-01-34-27-04-0 |
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
