0553-1-15-01-11-27-10-0
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Receptacles | Lead Time | 20 Days |
| Subcategory | Connector Contact | Product Category | Circuit Board Hardware - PCB |
| Standard Package | 500 | Factory Pack Quantity | 500 |
Compliance
| RoHS | Contains lead / RoHS non-compliant | EU RoHS | Not Compliant |
Electrical
| Contact Resistance | 10 | Current Rating (Max) | 3 |
Mechanical
| Depth | 1.39 | Height | 1.39 |
| Packaging | Bulk | Tail Type | No Tail |
| Shield Type | No | Termination | Press Fit |
| Contact Size | 11 | Socket Depth | 0.124" (3.15mm) |
| Mounting Type | Through Hole | Connector Type | Connector Socket |
| Contact Finish | Gold Over Nickel | Flange Diameter | 0.055" (1.40mm) |
| Contact Material | Beryllium Copper Alloy | Length - Overall | 0.140" (3.56mm) |
| Pin Hole Diameter | 0.031" (0.79mm) | Accepts Pin Diameter | 0.015" ~ 0.020" (0.38mm ~ 0.51mm) |
| Mounting Hole Diameter | 0.041" (1.04mm) | Contact Finish Thickness | 30µin (0.76µm) |
Product Info
| Gender | SKT | For Use With/Related Products | 0553-1-15-15-11-27-10-00553-1-15-80-11-27-10-0 |
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
