142-10-422-00-594000

Manufacturer	Mill-Max Mfg. Corp.
Description	Conn DIP Adapter HDR 22 POS 2.54mm Solder ST Thru-Hole Tube HEADER OPEN .018"DIA .400 22POS Headers & Wire Housings 22P DIP HDR OPEN FRAME .835L
Category	连接器解决方案板对板连接器板对板连接器

对参数有疑问？问 AI 助手

商业参数

产品类别	Headers & Wire Housings	标准包装数量	14
工厂包装数量	14

合规参数

RoHS

RoHS Compliant

欧盟RoHS

Compliant

电气参数

绝缘电阻

10000

最小输入电压

150VDC|100VAC

机械参数

颜色	Black	深度	12.7
间距	0.100" (2.54mm)	高度	24.39
包装方式	Tube	排间距	0.400" (10.16mm)
端接方式	Solder	触头类型	Post, Extended
安装类型	Through Hole	连接器类型	DIP, DIL - Header
接触镀层	Gold Over Nickel	排数	2
触头材料	Brass Alloy	壳体材料	Polychlorinated Terphenyl
总长度	27.8	触点数	22
绝缘材料 - 类型	Polychlorinated Terphenyl	位数	22
接触镀层厚度	10µin (0.25µm)

产品信息

类型

DIP Adapter

连接器性别

HDR

Documents & Media

PDF Document

142 Series (in.)

PDF Document

123-259654.pdf
