310-43-120-41-001000
| Category |
对参数有疑问？问 AI 助手
Business
| Product | DIP / SIP Sockets | Product Category | IC & Component Sockets |
| Standard Package | 1 | Factory Pack Quantity | 10 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85366930 | ||
Electrical
| Contact Resistance | 10 mohm | Current Rating (Max) | 3 A |
| Voltage - Input (Min) | 150VDC|100VAC | Voltage - Supply (Min) | 150VDC/100VAC |
Mechanical
| Color | Black | Depth | 2.54 mm |
| Pitch | 0.100" (2.54mm) | Height | 4.19 mm |
| Weight | 0 | Packaging | Bulk |
| Termination | Solder | Contact Type | Female Socket |
| Housing Color | Black | Mounting Type | Through Hole |
| Connector Type | Receptacle | Contact Finish | Gold Over Nickel |
| Mounting Style | Through Hole | Number of Rows | 1 |
| Contact Material | Beryllium Copper Alloy | Housing Material | Polychlorinated Terphenyl |
| Length - Overall | 50.8 mm | Termination Style | Solder Pin |
| Number of Contacts | 20 | Contact Termination | :Solder |
| Number of Positions | 20 | Contact Finish Thickness | 30µin (0.76µm) |
Product Info
| Type | Socket Strip | Gender | SKT |
| Series | :310 | DELETED | Compliant |
| Number of Positions Loaded | All | ||
Environmental
| Operating Temperature | -55C to 125C | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- 065-259662.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
