3603-0-07-21-00-00-08-0
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Pins | Product Category | Circuit Board Hardware - PCB |
| Standard Package | 500 | Factory Pack Quantity | 500 |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85366910 | ||
Mechanical
| Depth | 0.282in. | Height | 2.67 |
| Length | 14.93 mm | Weight | 0.002 |
| Plating | Gold over Nickel | Material | Brass Alloy |
| Packaging | Bulk | Tip Shape | :- |
| Insulation | Non-Insulated | Shield Type | No |
| Termination | Crimp | Length - Tail | 0.188" (4.78mm) |
| Mounting Type | Cable Mount | Terminal Type | Wire |
| Connector Type | Connector Socket | Contact Finish | Gold Over Nickel |
| Mounting Style | PCB | Flange Diameter | 0.102" (2.59mm) |
| Material - Body | BrassAlloy | Contact Material | Brass Alloy |
| Length - Overall | 0.588" (14.94mm) | Primary Material | PCPin |
| Diameter - Outside | 2.67 mm | Contact Termination | :Crimp |
| Pin Size - Below Flange | 0.040" (1.02mm) Dia | Contact Finish Thickness | 20µin (0.51µm) |
| 1st Connector Mounting Type | :Cable | ||
Product Info
| Type | Crimp | Gender | SKT |
| Manufacturer | 3603Series | For Use With/Related Products | :0.062 " thick boards |
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 183N.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
