6021-0-15-80-16-27-10-0
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Receptacles | Product Category | Circuit Board Hardware - PCB |
| Standard Package | 500 | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
Electrical
| Contact Resistance | 10 | Current Rating (Max) | 4.5 A |
Mechanical
| Depth | 1.98 | Height | 1.98 |
| Length | 4.83 mm | Plating | Tin over Nickel |
| Material | Beryllium Copper Alloy | Packaging | Bulk |
| Tail Type | No Tail | Shield Type | No |
| Termination | Solder | Contact Size | 16 |
| Socket Depth | 0.165" (4.19mm) | Mounting Type | Through Hole |
| Connector Type | Connector Socket | Contact Finish | Gold Over Nickel |
| Flange Diameter | 0.078" (1.98mm) | Contact Material | Beryllium Copper Alloy |
| Length - Overall | 0.190" (4.83mm) | Pin Hole Diameter | 0.051" (1.30mm) |
| Diameter - Outside | 1.98 mm | Accepts Pin Diameter | 0.022" ~ 0.034" (0.56mm ~ 0.86mm) |
| Mounting Hole Diameter | 0.062" (1.57mm) | Contact Finish Thickness | 30µin (0.76µm) |
Product Info
| Type | Pin Receptacles | Gender | SKT |
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- Pin Receptacles (in.)
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
