802-10-064-10-001000
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Headers & Wire Housings | Standard Package | 6 |
| Factory Pack Quantity | 6 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Voltage - Input (Min) | 150VDC|100VAC | ||
Mechanical
| Color | Black | Depth | 5.08 |
| Pitch | 0.100" (2.54mm) | Height | 8.13 |
| Packaging | Bulk | Row Spacing | 0.100" (2.54mm) |
| Termination | Solder | Contact Form | Male Pin |
| Contact Type | Male Pin | Lead Spacing | 0.100" (2.54mm) |
| Housing Color | Black | Mounting Type | Through Hole |
| Connector Type | Header, Unshrouded | Contact Finish | Gold Over Nickel |
| Number of Rows | 2 | Contact Material | Brass Alloy |
| Housing Material | Polychlorinated Terphenyl | Length - Overall | 81.28 |
| Termination Style | Through Hole | Height Above Board | 0.195" (4.95mm) |
| Number of Contacts | 64 | Number of Positions | 64 |
| Contact Length - Mating | 0.195" (4.95mm) | Contact Finish Thickness | 10µin (0.25µm) |
| Number of Positions/Bay/Row | All | ||
Product Info
| Type | Unshrouded Header | Gender | HDR |
| Series | 802 | Product Type | Headers |
| Output Configuration | Through Hole | Number of Positions Loaded | All |
