803-43-072-10-002000
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Headers & Wire Housings | Standard Package | 5 |
| Factory Pack Quantity | 5 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Voltage Rating | 1 kV | Contact Resistance | 10 |
| Current Rating (Max) | 4.5 A | Insulation Resistance | 10000 MOhms |
| Voltage - Input (Min) | 150VDC|100VAC | ||
Mechanical
| Color | Black | Depth | 5.08 |
| Pitch | 0.100" (2.54mm) | Height | 4.19 |
| Packaging | Bulk | Row Spacing | 0.100" (2.54mm) |
| Termination | Solder | Contact Type | Female Socket |
| Housing Color | Black | Mounting Type | Through Hole |
| Connector Type | Receptacle | Contact Finish | Gold Over Nickel |
| Number of Rows | 2 | Contact Material | Beryllium Copper Alloy |
| Housing Material | Polychlorinated Terphenyl | Length - Overall | 91.44 |
| Termination Style | Through Hole | Number of Contacts | 72 |
| Number of Positions | 72 | Contact Finish Thickness | 30µin (0.76µm) |
Product Info
| Type | Socket Strip | Gender | SKT |
| Series | 803 | Product Type | Sockets - PCB |
| Number of Positions Loaded | All | ||
Environmental
| Operating Temperature | - 55 C to + 125 C | ||
