830-10-050-10-001000
| Manufacturer | |
| Description | Conn Unshrouded Header HDR 50 POS 2mm Solder ST Thru-Hole CONN HEADER 50 POS 2MM Socket; Single Row Pin Header; 50; 2 mm; 0.023 mm (Pin 1); 0.019 mm (Pin 2) Headers & Wire Housings 2mm 50 POS CONNECTOR, HEADER, 50 POS, 1 ROW Socket;SingleRowPinHeader;50;2mm;0.023mm(Pin1),0.019mm(Pin2) |
| Category |
对参数有疑问？问 AI 助手
商业参数
| 产品类别 | Headers & Wire Housings | 标准包装数量 | 10 |
| 工厂包装数量 | 10 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 欧盟RoHS | Compliant |
| 海关税号 | 85366930 | ||
电气参数
| 最小输入电压 | 150VDC|100VAC | ||
机械参数
| 颜色 | Black | 深度 | 2 |
| 间距 | 0.079" (2.00mm) | 高度 | 7.9 |
| 重量 | 0 | 镀层 | 10uin.Gold |
| 包装方式 | Bulk | 排间距 | 2mm |
| 端接方式 | Solder | 触头类型 | Male Pin |
| 引脚直径 | 0.023mm(Pin1),0.019mm(Pin2) | 外壳颜色 | Black |
| 安装类型 | Through Hole | 连接器类型 | Header, Unshrouded |
| 接触镀层 | Gold Over Nickel | 排数 | 1 |
| 触头材料 | Brass Alloy | 壳体材料 | Nylon 46 |
| 总长度 | 100 | 端接样式 | Through Hole |
| 触点数 | 50 | 接触件端接 | :Through Hole Vertical |
| 位数 | 50 | 绝缘材料 - 材质 | HighTemperatureThermoplastic |
| 接触长度 - 配合 | 0.154" (3.91mm) | 接触镀层厚度 | 10µin (0.25µm) |
产品信息
| 类型 | Unshrouded Header | 连接器性别 | HDR |
| 系列 | 830 | 制造商全称 | 830Series |
| 产品子类型 | Headers | 加载位置数 | All |
| 适用产品/相关产品 | MM#1802Receptacle | ||
