22-28-4247
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | KK | Other Names | 0022284247 |
| Part # Aliases | 0022284247 42375-0199 | Standard Package | 1 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Voltage Rating | 250 V | Current Rating (Max) | 4 A |
Mechanical
| Color | Black | Pitch | 0.100" (2.54mm) |
| Packaging | Bulk | Termination | Solder |
| Contact Type | Male Pin | Mounting Type | Through Hole |
| Connector Type | Header, Unshrouded, Breakaway | Contact Finish | Gold |
| Number of Rows | 1 | Contact Material | Phosphor Bronze |
| Housing Material | Polyamide (PA) | Termination Style | Through Hole |
| Number of Contacts | 24 | Number of Positions | 24 |
| Contact Length - Mating | 0.320" (8.13mm) | Contact Finish Thickness | 30µin (0.76µm) |
Product Info
| Type | Breakaway | Series | 42375 |
| Product Type | Headers | Number of Positions Loaded | All |
