43680-2005
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | Sabre | Part # Aliases | 0436802005 |
| Product Category | Headers & Wire Housings | Standard Package | 10 |
| Factory Pack Quantity | 600 | ||
Compliance
| RoHS | Compliant | ||
Electrical
| Voltage Rating | 600 V | Current Rating (Max) | 18A |
| Connector - Voltage Input | Male | ||
Mechanical
| Color | Black | Depth | 35.56mm |
| Pitch | 0.295" (7.50mm) | Width | 19.15mm |
| Length | 41.4mm | Packaging | Bulk |
| Wire Gauge | 18-14 | Orientation | 直 |
| Contact Type | Male Blade | Mounting Type | Free Hanging (In-Line) |
| Connector Type | Plug | Fastening Type | Locking Ramp |
| Number of Rows | 1 | Housing Material | Nylon |
| Number of Contacts | 5 | Stacking Direction | Side to Side |
| Contact Termination | Crimp | Number of Positions | 5 |
| Material - Insulation | Polyamide (PA), Nylon | ||
Product Info
| Note | Contacts Not Provided | Type | Plug Housing |
| Gender | Male | Series | 43680 |
| CAD Drawing | 3D CAD Model | Product Type | Wire Housings |
| Base Product Number | 43680 | Application Specifics | Power, Wire-to-Wire |
| For Use With/Related Products | Sabre Plug | ||
Environmental
| Operating Temperature | -40°C ~ 75°C | ||
