51021-0600
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | PicoBlade | Part # Aliases | 0510210600 |
| Product Category | Headers & Wire Housings | Factory Pack Quantity | 2000 |
Compliance
| RoHS | RoHS Compliant | Tariff No | 85369010 |
Electrical
| Range deg/s | :MOLEX - PicoBlade 51021 Series | Voltage Rating | :125V |
| Voltage - Working | :125V | Contact Resistance | :20mohm |
| Dielectric Strength | :250V | Current Rating (Max) | :1A |
| Insulation Resistance | :100Mohm | ||
Mechanical
| Color | :Natural | Depth | 3.95mm |
| Pitch | 1.25mm | Width | 3.2mm |
| Length | 9.25mm | Weight | 0.002 |
| Termination | :Crimp | Body Material | :PBT Polyester |
| Mounting Type | Straight | Connector Type | :Wire to Board |
| Contact Finish | :Tin | Mounting Style | Wire |
| Number of Rows | 1 | Package / Case | :GF Nylon UL94V-0 |
| Contact Material | :Phosphor Bronze | Housing Material | PBT |
| Termination Style | Crimp | 1st Contact Gender | Socket (Female) |
| Number of Contacts | 6 | Contact Termination | :Crimp |
| 1st Connector Mounting Type | :PCB | ||
Product Info
| Gender | Female | Series | 51021 |
| CAD Drawing | 3D CAD Model | Product Type | Receptacles / Sockets - Housings |
| For Use With/Related Products | PicoBlade Wire-to-Board Connector, PicoBlade Wire-to-Wire Connector | ||
Environmental
| Operating Temperature | :85°C | ||
