No Image

0022288130

Manufacturer	Molex, LLC
Description	Conn Unshrouded Header HDR 13 POS 2.54mm Solder RA Thru-Hole Bag CONN HEADER 13POS .100 R/A TIN
Category	连接器解决方案板对板连接器板对板连接器

对参数有疑问？问 AI 助手

商业参数

标准包装数量

Bulk

合规参数

RoHS

Lead free / RoHS Compliant

机械参数

颜色	Black	间距	2.54 mm
包装方式	Bulk	端接方式	Solder
触头类型	Male Pin	安装类型	Through Hole, Right Angle
连接器类型	Header, Unshrouded, Breakaway	接触镀层	Tin Over Nickel
排数	1	触点数	13
位数	13	接触长度 - 配合	0.244" (6.20mm)
接触镀层厚度	100µin (2.54µm)

产品信息

类型	Unshrouded Header	连接器性别	HDR
加载位置数	All

Documents & Media

PDF Document

0022288130_PCB_HEADERS.pdf
