DMS-20PC-1-LM-C
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 12 | Lead Time | 20 Days |
| Unit Pack | 12 | Subcategory | Misc Products |
| Product Category | Digital Panel Meters | Standard Package | 12 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Display Type | LED | Number of Bits | 3.5 |
| Voltage Rating | 120 VAC | Current - Supply | 50 mArms |
| Voltage - Supply | 85 ~ 264VAC | Current - Input Bias (Max) | 50 mA |
Mechanical
| Depth | 17.45mm | Pitch | 33.93mm |
| Width | 35 mm | Packaging | Case |
| Termination | Screw Terminals | Mounting Type | Bezel Mount or Panel Mount, Rear Mounting Clip |
| Mounting Style | Panel, Board | Package / Case | 25.4 mm |
| Size / Dimension | 25.4 mm L x 35 mm W x 22 mm H | Termination Rows | 33.93mm |
| Cross Section Shape | 21.29mm | Panel Cutout Dimensions | Rectangular - 33.93mm x 21.29mm |
| Display Characters - Height | 0.370" (9.40mm) | ||
Product Info
| Type | Voltage (Voltmeter) | Series | DMS-20PC-1-LM |
| Features | Mounting Clip | Function | Digits Only |
| Face Size | 1.83" W x 1.28" H (46.4mm x 32.5mm) | Display Style | Red Characters, Black Background |
| Display Digits | 3 | Equipment Type | AC Voltmeters |
| Measuring Range | 85 ~ 264VAC | Digits or Characters | 3.5 |
| Other Specifications | 仅数字 | For Use With/Related Products | DMS-20PC-1-LM |
Environmental
| Operating Temperature | -25°C ~ 60°C | ||
Documents & Media
Sourcing & traceability
- Datasheet
- DMS-20PC-x.stp
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
