CKL12BTW01-003
| Manufacturer | |
| Description | Keylock Switches 19MM ON-ON RMVE 1POS TUBE KEY#003 3A LUG Switch Key Lock ON None ON SPDT 90° Tubular Key 3A 250VAC Solder Lug 30000Cycles Panel Mount SW KEYLOCK 19MM KEYCODE 003 250V |
| Category |
对参数有疑问？问 AI 助手
Business
| Part # Aliases | CK-L12BTS1-V2U-003 | Product Category | Keylock Switches |
| Standard Package | 1 | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
Electrical
| Circuit | SPDT | Voltage Rating | 250 V |
| Switch Function | ON - NONE - ON | Current Rating (Max) | 3 A |
| Voltage - Input (Min) | 250 | Switch Function/Rating | ON None ON |
| Contact Rating @ Voltage | 3 A at 250 V | ||
Mechanical
| Depth | 22 | Height | 40 |
| Contact Form | SPDT | Actuator Type | Tubular Key |
| Mounting Type | Panel Mount | Terminal Type | Solder Lug |
| Angle of Throw | 90° | Contact Finish | Silver |
| Contact Material | Silver | Housing Material | Zinc Alloy |
| Length - Overall | 22 | Material - Frame | Brass |
| Termination Style | Solder Lug | Number of Positions | 2 |
| Bushing, Grommet Type | 19 mm | Switch Actuation Level | SPDT |
| Material - Housing & Prism | Liquid Crystal Polymer/(Glass Fib... | ||
Product Info
| Type | High Security | Key Type | Tubular |
| Other Specifications | 90 deg | Key Removable Positions | 1 only |
Environmental
| Mechanical Life | 30000 | Operating Temperature | 70 |
