CKM12BFW01-001
| Manufacturer | |
| Description | Keylock Switches 16MM ON-ON RMVE 1POS FLAT KEY#001 3A LUG Switch Key Lock ON None ON SPDT 90° Flat Key 3A 250VAC Solder Lug 30000Cycles Panel Mount SW KEYLOCK 16MM KEYCODE 001 250V Switch Key Lock ON None ON SPDT 90? Flat Key 3A 250VAC Solder Lug 30000Cycles Panel Mount SWITCH, KEY OPERATED, SPDT, 3A, 250VAC KEYLOCK,SPDT,ON-NONE-ON,16MM,3AMPS |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | CKM12BFW01001 | Part # Aliases | CK-M12BFS1-UNC-001 |
| Product Category | Keylock Switches | Standard Package | 25 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85365080 | ||
Electrical
| Circuit | SPDT | Voltage Rating | 250 V |
| Switch Function | ON - ON | Voltage - Rated AC | 250V |
| Current Rating (Max) | 3 A | Current - Max/Contact | :3A |
| Voltage - Input (Min) | 250 | Switch Function/Rating | ON None ON |
| Contact Rating @ Voltage | 3A @ 250VAC | Voltage - Rated AC (Phase to Ground/Neutral) | :250V |
Mechanical
| Depth | 19 mm | Height | 35.2 mm |
| Weight | 0 | Contact Form | SPDT |
| Actuator Type | Flat Key | Mounting Type | Panel Mount |
| Terminal Type | Solder Lug | Angle of Throw | 90° |
| Contact Finish | Silver | Mounting Style | Panel |
| Contact Material | Silver | Housing Material | Polybutylene Terephthalate, Glass Fiber Reinforced |
| Length - Overall | 19 mm | Material - Frame | Brass |
| Termination Style | Solder Lug | Actuator Style/Size | :Flat |
| Number of Positions | 2 | Bushing, Grommet Type | 16 mm |
| Switch Actuation Level | SPDT | Contact Layout, Typical | :SPDT |
| Material - Housing & Prism | Liquid Crystal Polymer/(Glass Fib... | ||
Product Info
| Type | High Security | Key Type | Flat Key |
| Other Specifications | 90 deg | Key Removable Positions | 1 only |
Environmental
| Mechanical Life | 30000 | Operating Temperature | -25C to 70C |
| Operating Temperature - Junction | 70C | ||
