M2026BB1W01
| Manufacturer | |
| Description | Switch Toggle (ON) ON (ON) SP3T Large Bat Toggle Solder Lug 6A 250VAC 30VDC Panel Mount with Threads SWITCH TOGGLE SP3T 6A 125V SWITCH,SP3T(ON)ON(ON),.453INLRGB |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Circuit | SP3T | Voltage Rating | 125V |
| Switch Function | Mom-On-Mom | Current Rating (Max) | 6A (AC), 3A (DC) |
| Voltage - Input (Min) | 250 | Switch Function/Rating | (ON) ON (ON) |
Mechanical
| Depth | 12.7 | Height | 37.4 |
| Packaging | Bulk | Actuator Type | Standard Round |
| Mounting Type | Panel Mount with Threads | Terminal Type | Solder Lug |
| Bushing Thread | M12 x 1 | Contact Finish | Silver |
| Actuator Length | 11.50mm | Contact Material | Silver Alloy |
| Length - Overall | 13 | Actuator Material | Brass, Chrome Plated |
| Termination Style | Solder Lug | Actuator Style/Size | Large Bat Toggle |
| Switch Actuation Level | SP3T | Panel Cutout Dimensions | Circular - 12.50mm Dia |
Product Info
| Type | Miniature | Features | Epoxy Sealed Terminals |
| Illumination | Non-Illuminated | Electrical Life | 25,000 Cycles |
Environmental
| Mechanical Life | 100000 | Operating Temperature | -30°C ~ 85°C |
