SK14DG13
| Manufacturer | |
| Description | Switch Key Lock ON ON ON SP3T 45° Flat Key 0.1A 28VAC 28VDC 0.4VA PC Pins 30000Cycles Bracket Mount/Through Hole SWITCH KEYLOCK SP3T STR PC 28V Switch Key Lock ON ON ON SP3T 45� Flat Key 0.1A 28VAC 28VDC 0.4VA PC Pins 30000Cycle Panel Mount/Through Hole Switch Key Lock ON ON ON SP3T 45° Flat Key 0.1A 28VAC 28VDC 0.4VA PC Pins 30000Cycle Bracket Mount/Through Hole SWITCH, KEY OPERATED, SP3T, 0.1A, 28VAC Switch,Keylock,SP3T,KeyRemovable1,2and3POS,On/On/On,StraightW/Bracket |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 50 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85365019 | ||
Electrical
| Circuit | SP3T | Power - Rated | 0.4 |
| Voltage Rating | 28 | Voltage - Rated AC | 28V VAC |
| Current Rating (Max) | 0.1 A | Voltage - Input (Min) | 28 |
| Switch Function/Rating | ON ON ON | Contact Rating @ Voltage | 0.4VA @ 28VAC/DC |
| Voltage - Supply (Vcc/Vdd) | :28V | Voltage - DC Spark Over (Nom) | 28V VDC |
| Voltage - Rated AC (Phase to Ground/Neutral) | :28V | ||
Mechanical
| Depth | 14.5 mm | Height | 21 mm |
| Weight | 0 | Actuator Type | Flat Key |
| Mounting Type | Bracket Mount/Through Hole | Terminal Type | PC Pins |
| Angle of Throw | 45° | Contact Finish | Gold |
| Contact Material | Beryllium Copper | Length - Overall | 15.74 mm |
| Material - Frame | Brass Alloy | Termination Style | PC Pin |
| Actuator Style/Size | :Flat | Number of Positions | 3 |
| Switch Actuation Level | SP3T | Contact Layout, Typical | :SP3T |
| Material - Housing & Prism | (Glass Fiber/Polyamide)/N/A | ||
Product Info
| Type | Process Sealed | Key Type | Flat Key |
| Key Removable Positions | 1, 2 and 3 | ||
Environmental
| Mechanical Life | 30000 | Operating Temperature | -25C to 70C |
| Operating Temperature - Junction | 70C | ||
