4712KL-04W-B30-P00
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 98 Days | Subcategory | Blowers and Fans |
| Standard Package | 10 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 84145920 |
Electrical
| Noise | 44 dB | Speed | Clockwise |
| Input Range | 6 to 13.8 | Range deg/s | :2800rpm |
| Power (Watts) | 5.76W | Power - Rated | 5.76 |
| Voltage Range | 6 ~ 13.8VDC | Voltage Rating | 12VDC |
| Current - Output | 0.48 | Voltage - Supply | :12VDC |
| Power Supply Type | :Wire Leaded | Current Rating (Max) | 0.480A |
| Power - Average Forward | :5.76W | ||
Mechanical
| RPM | 2800 RPM | Depth | :32mm |
| Width | :119mm | Height | 32 |
| Weight | 0.529 lb (239.95g) | Air Flow | 99.9 CFM (2.83m³/min) |
| Fan Type | Tubeaxial | Material | :Plastic |
| Flow (CFM) | :2.83m³/min | Flow (SCFM) | :99.9cu.ft/min |
| Termination | Lead Wire | Bearing Type | Ball |
| Height (Max) | :119mm | Mounting Type | Flange Mount |
| Static Pressure | 0.241 in H2O (60.0 Pa) | Housing Material | Plastic |
| Length - Overall | 119 | Material - Blade | Plastic |
| Material - Frame | Plastic | Maximum Pressure | 60Pa |
| Size / Dimension | Square - 119mm L x 119mm H x 32mm W | Color - Connectors | :Black |
| Panel Cutout Shape | :126.0mm | ||
Product Info
| Series | :4712KL | Function | :DC |
Environmental
| Rated Life | 100000 hrs @ 25°C | Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Operating Temperature - Junction | :100000h | ||
Documents & Media
Sourcing & traceability
- Datasheet
- 4712kl.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
