FBA09A24U1AZ
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | Q1178293 | Standard Package | 100 |
Electrical
| Noise | 43 dB | Power (Watts) | 2.64W |
| Voltage Range | 14 ~ 27.6VDC | Voltage Rating | 24VDC |
| Current Rating (Max) | 0.430A | ||
Mechanical
| RPM | 3450 RPM | Weight | 0.243 lb (110.22g) |
| Air Flow | 48.0 CFM (1.36m³/min) | Fan Type | Tubeaxial |
| Termination | 2 Wire Leads | Bearing Type | Hydro-wave (HWB) |
| Static Pressure | 0.197 in H2O (49.0 Pa) | Size / Dimension | Square - 92mm L x 92mm H x 25.5mm W |
Environmental
| Rated Life | 50000 hrs @ 40°C | Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
