点击放大查看
180-026-173L000
| Manufacturer | |
| Description | D-Sub High Density Connectors 26P MALE CRIMP POKE NICKEL SHELL CONN DB26 MALE HD CRIMP NICKEL D-SUB SHELL, DB26, CRIMP, PLUG, 26WAY |
| Category |
商业参数
| 产品类别 | D-Sub High Density Connectors | 标准包装数量 | 50 |
| 工厂包装数量 | 50 | ||
合规参数
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| 海关税号 | 85369010 | ||
电气参数
| 最大额定电流 | 2 A | ||
机械参数
| 重量 | 0.0056 | 包装方式 | Bulk |
| 触头类型 | Signal | 安装类型 | Vertical |
| 外壳镀层 | Nickel | 连接器类型 | Plug for Male Contacts |
| 法兰特征 | Housing/Shell (Unthreaded) | 安装样式 | Wire |
| 排数 | 3 | 外壳材料（壳体） | Steel |
| 连接器样式 | D-Sub, High Density | 本体材料 | :Steel |
| 端接样式 | Crimp | 触点数 | 26 |
| 位数 | 26 | 外壳尺寸-插件 | :DA |
| 外壳材料及表面处理 | Steel, Nickel Plated | 外壳尺寸，连接器布局 | 2 (DA, A) High Density |
产品信息
| 备注 | Contacts Not Provided | 连接器性别 | Male |
| 系列 | 180 | 产品特性 | Grounding Indents |
| 适用产品/相关产品 | :180 Series Crimp Pin Contacts | ||
环境参数
| 工作温度 | -50°C ~ 100°C | ||
