PCA9533D/01,112
| Category |
对参数有疑问？问 AI 助手
Business
| Part # Aliases | PCA9533D/01 | Product Category | LED Lighting Drivers |
| Standard Package | Rail / Tube | Factory Pack Quantity | 100 |
| Standard Package Name | SOIC | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
Electrical
| Frequency | 400kHz | Power - Rated | 400 mW |
| Voltage Rating | 2.3 V to 5.5 V | Current - Output | 25mA |
| Current - Supply | 550 uA | Voltage - Supply | 2.3 to 5.5 V |
| Number of Outputs | 4 | Number of Channels | 4 |
| Voltage - Supply (Min) | 5.5 | Power - Average Forward | 400 mW |
| Power Dissipation (Max) | 400 mW | Current - Output High, Low | 25000(Min) uA |
Mechanical
| Weight | 0.17 g | Packaging | Tube |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 8SO |
| Package Quantity | SO | Number of Positions | 8 |
| Supplier Device Package | 8-SO | ||
Product Info
| Spg | 200 | Type | RGB |
| Topology | Open Drain, PWM | Manufacturer | NXP Semiconductors |
| Number of Units | 1 | Number of Segments | 4 |
| Utilized IC / Part | LED controller | Internal Connection | Yes |
Environmental
| Operating Temperature | + 85 C | ||
Documents & Media
Sourcing & traceability
- Datasheet
- PCA9533.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
