G2R-1-S-T130 DC24
| Category |
对参数有疑问？问 AI 助手
Business
| Part # Aliases | G2R-1-ST130-DC24 | Product Category | General Purpose Relays |
| Standard Package | 1 | Factory Pack Quantity | 100 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Coil Type | Non-Latching | Coil Power | 530 mW |
| Coil Current | 21.6 mA | Release Time | 10ms |
| Coil Resistance | 1.113 K Ohms | Voltage - Supply | 24 VDC |
| Switching Voltage | 440 VAC, 125 VDC | Vgs(th) (Max) @ Id | 3.6 VDC |
| Power - Average Forward | 0.53 W | Vce(on) (Max) @ Vge, Ic | 16.8 VDC |
| Contact Rating (Current) | 10 A | ||
Mechanical
| Width | 13 mm | Height | 35.5 mm |
| Length | 29 mm | Packaging | Bulk |
| Contact Form | SPDT | Mounting Type | Socketable |
| Mounting Style | Plug In | Contact Material | Silver Alloy |
| Termination Style | Plug In, QC - 0.187" (4.7mm) | Contact Termination | Pin |
Product Info
| Type | Relays | Series | G2RS |
| Relay Type | General Purpose | Card Standard | Power Relay |
Environmental
| Operate Time | 15ms | Operating Temperature | -40°C ~ 70°C |
