OA172AN-11-2TB
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Fans | Product Category | Fans |
| Standard Package | 12 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Noise | 42 dB | Speed | 2400 RPM |
| Power (Watts) | 20.0W | Power - Rated | 20 W |
| Voltage Range | 80 ~ 130VAC | Voltage Rating | 115VAC |
| Voltage - Supply | 115 V | ||
Mechanical
| RPM | 2400 RPM | Air Flow | 170.0 CFM (4.81m³/min) |
| Fan Type | Tubeaxial | Termination | 2 Terminals |
| Bearing Type | Ball | Static Pressure | 0.490 in H2O (122.1 Pa) |
| Housing Material | Aluminum | Material - Blade | Polybutylene Terephthalate (PBT) |
| Material - Frame | Aluminum | Size / Dimension | Round - 172mm Dia x 50.8mm W |
| Termination Style | Terminals | ||
Product Info
| Type | Axial Fans | Function | AC |
Environmental
| Rated Life | 60000 hrs @ 40°C | Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
Documents & Media
Similar Parts
Sourcing & traceability
- Datasheet
- Orion Fan Catalog
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
