OD8038-12HBVXC10A
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Fans | Product Category | Fans |
| Standard Package | 1 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Noise | 57 dB | Speed | 6300 RPM |
| Power (Watts) | 14.0W | Power - Rated | 14 W |
| Voltage Rating | 12VDC | Voltage - Supply | 12 V |
| Current Rating (Max) | 1.2A | ||
Mechanical
| RPM | 6300 RPM | Air Flow | 99.0 CFM (2.80m³/min) |
| Fan Type | Tubeaxial | Termination | 4 Wire Leads |
| Bearing Type | Ball | Static Pressure | 0.810 in H2O (201.8 Pa) |
| Housing Material | Polybutylene Terephthalate (PBT) | Material - Blade | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Material - Frame | Polybutylene Terephthalate (PBT), Fiberglass Reinforced | Size / Dimension | Square - 80mm L x 80mm H x 38mm W |
| Termination Style | Wire Leads | ||
Product Info
| Type | Axial Fans | Features | PWM Control; Speed Sensor (Tach) |
| Function | DC | ||
Environmental
| Rated Life | 50000 hrs @ 40°C | Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- Orion Fan Catalog
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
