OD9225-12HB
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Fans | Product Category | Fans |
| Standard Package | 1 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Noise | 35 dB | Speed | 2800 RPM |
| Power - Rated | 120 mW | Voltage Range | 7 ~ 17VDC |
| Voltage Rating | 12VDC | Voltage - Supply | 12 V |
| Current Rating (Max) | 0.250A | Noise Figure (dB Typ @ f) | 35 dB |
Mechanical
| RPM | 2900 RPM | Size | 3.6x1(92x25)In.(mm) |
| Air Flow | 53.0 CFM (1.50m³/min) | Fan Type | Tubeaxial |
| Material | Plastic | Rotation | CCW |
| Termination | 2 Wire Leads | Bearing Type | Ball |
| Operating Force | 0.130 in H2O (32.4 Pa) | Static Pressure | 0.130 in H2O (32.4 Pa) |
| Housing Material | Polybutylene Terephthalate (PBT) | Material - Blade | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Material - Frame | Polybutylene Terephthalate (PBT), Fiberglass Reinforced | Primary Material | Fans |
| Size / Dimension | Square - 92.5mm L x 92.5mm H x 25mm W | Termination Style | Wire Leads |
| Fan Accessory Type | 3.6x1(92x25)In.(mm) | Dimensions - Overall | 3.6x3.6x1In. |
Product Info
| Type | Square | Series | OD9225 |
| Function | DC | Direction | ExhaustoverStruts |
| Switch Type | DC | Manufacturer | OD9225Series |
| Configuration | Square | ||
Environmental
| Rated Life | 60000 hrs @ 40°C | Operating Temperature | -4 ~ 176°F (-20 ~ 80°C) |
| Thermal Resistance @ Natural | 53CFM | Operating Temperature - Junction | 80°C |
Documents & Media
Sourcing & traceability
- Datasheet
- Orion Fan Catalog
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
