ECQ-V1H104JL
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Metallized Plastic Film Capacitors | Lead Time | 84 Days |
| Subcategory | Capacitor Plastic Film | Product Category | Film Capacitors |
| Standard Package | Bulk | Factory Pack Quantity | 1000 |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | ||
Electrical
| Voltage | 50 Vdc | Tolerance | 5 % |
| Capacitance | 0.1 uF | Voltage Rating | 50 V |
| Dissipation Factor (DF) | 1 | ||
Mechanical
| Size | 7.3 X 4 X 5 | Depth | 4(Max) mm |
| Width | 4 mm | Height | 5(Max) mm |
| Diameter | Not Required mm | Packaging | Bulk |
| Lead Style | Straight | Termination | PC Pins |
| Construction | Radial | Height (Max) | 6 mm |
| Lead Spacing | 5 mm | Pin Diameter | 0.5 mm |
| Pitch - Post | 5 mm | Mounting Type | Through Hole |
| Mounting Style | Through Hole | Package / Case | 7.3(Max) X 4(Max) X 5(Max) |
| Material - Core | Polyester Metallized | Length - Overall | 7.3(Max) mm |
| Size / Dimension | 0.287" L x 0.157" W (7.30mm x 4.00mm) | Termination Style | Radial |
| Dielectric Material | PET | Height - Seated (Max) | 0.236" (6.00mm) |
| Diameter - Small Outside | 0.5 mm | ||
Product Info
| Type | Radial | Series | ECQV(L)(M) |
| Applications | General Purpose | Failure Rate | Not Required |
| Manufacturer | ECQV Series | Product Type | AC Pulse, Suppression |
| Industry Aliases | ECQV1H104JL | ||
Environmental
| Temperature Range | –40 to 105 °C | Operating Temperature | -40 to 105 °C |
| Temperature Coefficient | PET | Operating Temperature - Junction | 105 °C |
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- ABD0000CE8.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
