EEUFC1J101
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 20000 | Unit Pack | 200 |
| Standard Package | Bulk | ||
Compliance
| RoHS | RoHS Compliant Part | ||
Electrical
| Voltage | 63 Vdc | Impedance | 256mΩ |
| Tolerance | 20 % | Capacitance | 100 uF |
| Voltage Rating | 63VDC | Capacitance @ Vr, F | electrolytic |
| Voltage - Supply (Min) | 63V | Ripple Current @ Low Frequency | 535 mA |
| Ripple Current @ High Frequency | 535 mA | ||
Mechanical
| Pitch | 5 | Height | 12.5 mm |
| Length | 12.5 | Weight | 1.51 g |
| Diameter | 10 mm | Size - Body | Ø10 x 12.5mm |
| Termination | Radial | Construction | Radial |
| Pitch - Post | 5 mm | Mounting Type | Through Hole |
| Material - Blade | AluminumElectrolytic | Package Quantity | 200 |
| Pitch - Connector | 5mm | Termination Style | Radial |
| Diameter - Outside | 10 | Shell Size - Insert | 10mmDia.x12.5mmL |
Product Info
| Spg | 200 | Electrical Life | 3000 h |
| Number of Units | 1 | ||
Environmental
| Rated Life | 3000h | Operating Temperature | -55 to 105 °C |
| Operating Temperature - Junction | 105°C | ||
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- ABA0000CE22.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
