AXK740147G
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 255-2534-2 | Standard Package | Tape & Reel |
| Factory Pack Quantity | 3000 | ||
Compliance
| RoHS | RoHS Compliant By Exemption | EU RoHS | Compliant |
Electrical
| Voltage Rating | 60 V | Contact Resistance | 70 mohm |
| Current Rating (Max) | 0.3 A | Voltage - Input (Min) | 60VDC|60VAC |
| Voltage - Supply (Min) | 60VDC/60VAC | ||
Mechanical
| Depth | 3.75 mm | Pitch | 0.4 mm |
| Height | 1.5 mm | Packaging | Reel |
| Termination | Solder | Housing Color | Black |
| Mounting Type | Vertical | Connector Type | Socket, Center Strip Contacts |
| Contact Finish | Gold Over Nickel | Mounting Style | SMD/SMT |
| Number of Rows | 2 | Contact Material | Copper Alloy |
| Housing Material | Liquid Crystal Polymer (LCP) | Length - Overall | 10.3 mm |
| Termination Style | SMD | Height Above Board | 0.059" (1.50mm) |
| Number of Contacts | 40 | Number of Positions | 40 |
| Mated Stacking Heights | 1.5mm | ||
Product Info
| Type | Board to Board | Gender | SKT |
| Series | P4 | Product Type | Sockets |
Environmental
| Operating Temperature | -55C to 85C | ||
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- How to Read Date Codes
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
