DS2E-S-DC5V
| Manufacturer | |
| Description | Electromechanical Relay DPDT 2A 5VDC 125Ohm Through Hole Low Signal Relays - PCB 2A 5VDC DPDT SEALED PCB RELAY GENERAL PURPOSE DPDT 2A 5V DPDT DIL monostable relay,3A 5Vdc coil Relay;E-Mech;Sensitive;DPDT-NO/NC;Cur-Rtg 2A;Ctrl-V 5DC;Vol-Rtg 30DC;PCB Mnt Electromechanical Relay DPDT 3A 5VDC 125Ohm Through Hole RELAY, PCB, DPCO, 5VDC Relay;E-Mech;Sensitive;DPDT-NO/NC;Cur-Rtg2A;Ctrl-V5DC;Vol-Rtg30DC;PCBMnt Signal Relay Coil Voltage: 5 VDC Contact Configuration: 2C DPDT Current: 2 Amps Mounting: PC Board Operating Function: Single Side Stable Signal relay 5 VDC 125 Ohm 200 mW THD, DS2E-S-DC5V, Panasonic Panasonic 双刀双掷 PCB（印刷电路板）安装 非闭锁继电器, 5V dc |
| Category |
商业参数
| 产品类别 | Low Signal Relays - PCB | 标准包装数量 | 50 |
| 工厂包装数量 | 50 | ||
合规参数
| RoHS | RoHS Compliant By Exemption | SVHC | :No SVHC (20-Jun-2013) |
| 海关税号 | 85364900 | 抗辐射加固 | No |
电气参数
| 线圈类型 | Single Side Stable | 线圈功率 | 200 mW |
| 最大功率 | 60 W | 线圈电流 | 40 mA |
| 线圈电压 | 5V | 释放时间 | 5ms |
| 额定功率 | 60W/125VA | 隔离类型 | 1500V rms |
| 可见输出 | No | 核心电压 | :250V |
| 负载电压 | :1500V | 额定电压 | 220 V |
| 线圈电阻 | 125 Ohm | 最大频率 | :20Hz |
| 极数 | :2 | 供电电压 | 5 V |
| 开关电压 | 250VAC, 220VDC - Max | Vgs(th)（最大）@ Id | 0.5 VDC |
| 额定交流电压 | 250V | 二极管配置 | No |
| 最大额定电流 | 2 A | 输出浪涌功率 | 125 VA |
| 最大触点电流 | :3A | 绝缘电阻 | :100Mohm |
| 最小输入电压 | 250 V | 平均正向功率 | 200 mW |
| 集电极-发射极饱和电压（最大）@ Vge, Ic | 3.5 VDC | 触点额定电流 | 3 A |
| 触点额定值 @ 电压 | 2 A at 30 VDC | 供电电压 (Vcc/Vdd) | :30V |
| 直流反向电压（Vr）（最大） | 220 V | 高侧电压（自举）最大 | 3.5VDC |
| 额定交流电压（相对地/中性线） | :250V | ||
机械参数
| 密封 | Sealed | 深度 | 9.9mm |
| 宽度 | :20mm | 高度 | 9.9mm |
| 长度 | 20mm | 重量 | 0.004 |
| 包装方式 | Tube | 触点形式 | 2 Form C (DPDT-BM) |
| 高度（最大） | :9.8mm | 引脚间距 | :5.08mm |
| 柱间距 | :7.62mm | 安装类型 | Through Hole |
| 端子类型 | Through Hole | 安装样式 | Through Hole |
| 封装形式 | DIP | 触头材料 | Silver/Gold Clad |
| 总长度 | 20 mm | 端接样式 | Solder Terminal |
| 位数 | 8 | 安装孔直径 | :0.9mm |
| 典型触点布局 | DPDT | ||
产品信息
| 类型 | General Purpose Relay | 系列 | :DS |
| 产品特性 | Sealed - Amber | 继电器类型 | General Purpose |
| 按下测试类型 | No | 应用细节 | General Purpose |
环境参数
| 动作时间 | 10ms | 机械寿命 | :100,000,000 Operations |
| 开关次数 | :100000000 | 工作温度 | -40 to 70 °C |
