LXS8-PW30
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | LUXEON | Standard Package | 500 |
Compliance
| RoHS | Compliant | ||
Electrical
| Voltage | 29V | Wavelength | 3045K |
| Luminous Flux | 1390 lm | Viewing Angle | 115 ° |
| Current - Output | 700mA | Driver Circuitry | Yes |
| Voltage - Supply | 25.6V | LED Forward Current | 700 mA |
| LED Forward Voltage | 29 V | Current Rating (Max) | 900mA |
| Light Emitting Surface (LES) | 8.06mm Diameter | Lumens/Watt @ Current - Test | 78 lm/W |
| Flux @ 85degC, Current - Test | 1390 lm | ||
Mechanical
| Color | White, Warm | Width | 8.72 mm |
| Height | 6.09 mm | Length | 8.72 mm |
| LED Color | White | Packaging | Tray |
| Lamp Color | 3000 K | Lens Style | Circular |
| Mounting Type | PCB Surface Mount | Connector Type | No |
| Mounting Style | SMD/SMT | Number of Pins | 3 |
| Connector Usage | No | Material - Core | InGaN |
| Size / Dimension | 13.87mm L x 12.87mm W | Color - Background | 3000K |
| Illumination Color | Warm White | CRI (Color Rendering Index) | 80 |
Product Info
| Type | Chip On Board (COB) | Series | LUXEON S1000 |
| CCT (K) | 3000K | Features | Lens - Dome |
| Configuration | Square | Number of LEDs | 1 |
| Channels per IC | Square | ||
Environmental
| Operating Temperature | - 40 C | Thermal Resistance of Package | 1.3°C/W JC |
| Luminous Flux @ Current/Temperature | 1390 lm | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- DS80-275223.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
